New, Sams B3 2628 3-Rolls Double Pinch Plate Bending Machine
- Length of rolls 2550mm
- Rolling capacity (cold) 19mm (at dia 1425mm)
- Prebending capacity (cold) 15mm (at dia 1425mm)
- Rolling capacity (cold) 15mm (at diameter 370mm)
- Prebending capacity (cold) 11mm (at diameter 370mm)
- Yield strength 260 N/mm2
- Cone capacity by continuous rolling = 60% of prebending thickness
- Cone capacity by pressing = 100% of prebending thickness
- Top roll diameter 285mm
- Bottom rolls diameter 265mm
- Powered driving rolls: 3
- Hydraulic motors: 3 (directly splined on the rolls shaft)
- Surface speed: automatic by hydraulic unit
- Rolling speed 5 mt/min
- Rolls movement adjustment: hydraulic
- Main motor 20 hp
- Lubrication system: centralized
- Overall Dimensions: 5,000 mm (L) x 1,200 mm (W) x 1,700 mm (H)
- Weight approximately 7.0 ton
We are the supplier, seller and owner of the above new machine.
The machine is for sale EX-STOCK and is currently located in our warehouse in Ipoh, Malaysia.
Plate Bending Rolls Listing |
If you require additional information on this machine
or on any other new or used plate bending rolls (plate rolls, plate rolling machine, plate rollers, plate bender, plate bending machine, bending rollers machine, bending machine),
please let us know. We would be more than happy to assist.
For sales and price enquiry, please contact Zhongyang Engineering through
telephone, fax or email.
