RZ1871-2:
New, China (Dahe) M4215 Vertical Honing Machine
- Honing dia. 50 - 150mm
- 4 x Honing Heads: 50mm (3 sticks), 75mm, 100mm, 125mm (6 sticks)
- 2 x Arbors (suitable for 4 heads above)
- Max. honing depth 400mm
- Spindle speeds (4 steps) 112, 160, 224, 315 rpm
- Max. spindle traverse 370mm.
- Spindle reciprocation speeds 3 - 18 m/min
- Distance between spindle axis and column face 350mm.
- Worktable surface 480 x 1100mm.
- Worktable height 470mm
- Worktable traverse: longitudinal 60mm, traverse 800mm
- Hydraulic pump 40 L/min.
- Max. working pressure of hydraulic system 22 kgf/cm sq.
- Supply flow of coolant pump 22 L/min.
- Total output 4.525 kW.
- Motor for spindle rotation 2.2 kW.
- Hydraulic pump motor 2.2 kW.
- Coolant pump motor 0.125 kW
- Dimensions (LxWxH): 1280mm x 1680mm x 2670mm
- Weight 2100 kgs
If you require additional information on this machine
or on any other new or used honers (honing machines) that we carry,
please let us know. We would be more than happy to assist.
For sales enquiry, please contact Zhongyang Engineering through
telephone, fax or email.
