NLLDM084:
New, China CW6263C/3000 Gap Bed Lathe
- Max. swing over bed 630mm
- Max. swing over saddle 350mm
- Between centres 3000mm
- Width of gap 320mm
- Swing over gap 800mm
- Width of bed 550mm
- Spindle speed 7.5 - 1000 rpm (18 speeds)
- Longitudinal feed 0.1 - 24.3 mm/rev (64)
- Cross feed 0.05 - 12.15 mm/rev (64)
- Rapid traverse speed 3.8 m/min
- Metric thread 1 - 240mm (39)
- Whitworth thread 14 - 1 TPI (26)
- Module thread 0.5 - 120mm (53)
- Diametric pitch thread 28 - 1 (24)
- Max. travel of cross slide 445mm
- Travel of top slide 200mm
- Main motor 11 kW
- Rapid traverse motor 1.1 kW
- Coolant pump motor 0.09 kW
- Wooden packing: 5,460 mm (L) x 1,150 mm (W) x 2,080 mm (H)
- Net weight 4,650 kgs; Gross weight 6,250 kgs
If you require additional information on this machine
or on any other new or used lathe (lathe, metal lathe, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, brake lathe, mini lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe) that we carry,
please let us know. We would be more than happy to assist.
For sales enquiry, please contact Zhongyang Engineering through
telephone, fax or email.
