NLLTK010:
Takang TK630 x 1500 High Speed Precision Lathe
- Swing over bed 630mm
- Swing over cross slide 450mm
- Swing over gap 770mm
- Between centres 1500mm
- Spindle bore 85mm
- Spindle nose D1 - 8, A2 - 11 (opt.)
- Spindle speeds (steps) 24 - 1520 RPM (18)
- Spindle motor (option) 10 HP (15 HP)
- Lead screw 6mm / pitch (4 TPI)
- Metric / pitch, range (numbers) 0.5 - 7mm (24)
- Inch, range (numbers) 4 / 56 TPI (36)
- Module / pitch, range (numbers) 0.25 - 3.5 M (16)
- DP, range (numbers) 8 - 112 P (36)
- Longitudinal feeds, mm/rev. 0.06 - 0.88
- Cross feeds, mm/rev. 0.03 - 0.44
- Quill diameter / centre taper 75mm / MT5
- Travel 170mm
- Bed width 350mm
- Cross slide travel 330mm
- Compound rest travel 150mm
- Coolant pump motor 1/8 HP
- Overall Dimensions: 2,790 mm (L) x 1,200 mm (W) x 1,800 mm (H)
- Weight approximately 3.1 ton
If you require additional information on this machine
or on any other new or used lathe (used lathe, metal lathe, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, brake lathe, mini lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe) that we carry,
please let us know. We would be more than happy to assist.
For sales enquiry, please contact Zhongyang Engineering through
telephone, fax or email.
